The WCAM25-SXXHA series products provide customers with high stability, ultra small volume modular switching power supplies. This series of modular power supplies has small volume, high reliability, and high
Features such as high isolation voltage and high cost-effectiveness. This series of products is mainly used for instruments and other related equipment in heavy industrial environments, and is necessary for applications in more severe electromagnetic compatibility environments
Please refer to the application circuit
Ultra small size, high power density, and high conversion efficiency
Wide voltage input (85-305Vac, 100-400Vdc)
EMC up to level 4 (EN61000-6-2, A-level heavy industry standard)
High efficiency, low ripple noise, output protection
Low power consumption, green environmental protection, no-load loss<0.1W
High efficiency, with an efficiency of up to 87%
Working temperature: -40~+70 ℃
Isolation voltage up to 3000VAC
Environmentally friendly design, compliant with RoHS directive
100% full load aging
Winchen Power
Contact:charles
Mobile:86-15692172948
Email:sales@winchen-power.com
Add:Nanshan District, Shenzhen Guangdong Provice
