WCAM50-SXXHA 50W AC/DC 400v/48v isolated power converter inverter

The WCAM50-SXXHA series product is a high stability, ultra small volume (70 * 48 * 23.5mm) modular switching power supply. This series of modular power supplies has a small volume

Features such as high reliability, high isolation voltage, and high cost-effectiveness. This series of products is mainly used for instruments and other related equipment in heavy industrial environments, such as for electromagnetic compatibility

In poor environments, reference must be made to the application circuit.

electrical

Ultra small size, high power density, and high conversion efficiency

Wide voltage input (85-305Vac, 100-400Vdc)

EMC up to level 4 (EN61000-6-2, A-level heavy industry standard)

Low ripple, low noise

Output overload, short circuit protection

Low power consumption, green environmental protection, no-load loss<0.1W

High efficiency, with an efficiency of up to 88%

Working temperature: -40~+70 ℃

Isolation voltage up to 3000VAC

Environmentally friendly design, compliant with RoHS directive
